Feature
Interchangeable manifolds for 8- and 12-well strips
One or more strips of ELISA Plate washing keyboard choice directly
Minimal residual volume (<1μL/well)
Dispense precision Cv<2%
Detachable ELISA Plate pallet, convenient for the pallet clearing and sterilization
Cleaning head 5-locations location adjusted,
Shaking or soak time programmed.
Automatic waste and lotion and distilled water liquid warning
Built-in internal-temperature cyclic ELISA Plate pallet incubator(patent)
temperature precision 37± 0.3℃
Specification:
Micro-plate Types: 48 / 96-well U-/V- / Flat-bottom plates or strips
Residual Volume: ≤ 1μl / well typical
Dispense volume: 50μl-950μl, adjustable
Washing Cycles:1-99, optional
Washing Mode:1-12, rows and ranksselectable
Soaking Time:0-999s, adjustable
Shaking Time:0-999s, adjustable
Display:Large LCD
Channel:2 channels for washing liquid, 1 channel for waste liquid
Memory:Up to 100 programs can be stored
Interface:RS232
Power Supply:220110VAC ± 10%, 5060Hz
Temperature:5℃-30℃ wet≤90%
Dimension:43*38*12cm
Net Weight:12KG
