LTX21A portable diagnosis digital X-ray machine
LTX21A portable diagnosis digital X-ray machine

LTX21A portable diagnosis digital X-ray machine

Model NO.
LTX21A
Price:
USD 4,300.00-4,600.00 / set
Minimum order quantity:
1 set
Supply Ability:
100.0 set / Month
Country of Origin:
Huangpu
Quantity:
  • Properties:Medical X-ray Equipments & Accessories
  • Focus size:2.3mm
  • Weight:260Kg
  • Voltage scope:40-90kV KV with 26 alternations
  • Instruments container:an additional option
  • Max. photograph tube current::50mA
  • certificate:CE,ISO
  • Power capability:50-90KV
  • Grid density::N=28
  • Moving range of bed surface:640mm in Length,200mm in breadth
  • Power Source:Electric
  • Warranty:1 Year
  • After-sale Service:Online technical support
  • Shelf Life:1years
  • Quality Certification:ce
  • Instrument classification:Class II
  • Safety standard:None
  • Place of Origin:CN;GUA
  • Model Number:LTX21A
  • Brand Name:Leytemed
  • Material:other
Product Description

portable diagnosis digital X-ray machine

MEDICAL X-RAY MACHINE

USE

General radiography,Filter-ray-filter radiograph


Unit Configuration

Control ,HT generator unit,Ht cable,X-ray tube unit,Radiographic table-X-ray source column ,Collimator


Function

The unit can used for general radiography, Bucky radiography of body’s head, chest, foot and hand, bones in lying

Main Features

1、meter-indicating
2、single-table single tube
3、single-phase, full wave rectification
4、stationary anode x-ray tube assembly
5、X-ray tube filament s voltage regulator, space charge compensator
Radiograph plain table wimple structure and easy assembling
ITEM
CONTENTS
INDEX
Demand of power supply
Capacity
Two-phase 30KVA
Voltage、Frequency
380V/220V ±10%50HZ ±0.5Hz
Intemal resistance
2Ω(380V) 0.6 Ω(220V)
Power supply
Adjustable range
380±10% at220V being adjustable continuously
Radiograph
Voltage
50-90KV
current
Small focus: 15mA,Big focus:30mA 60mA 100mA
time
0.04~6.35s 23grades together grading a according to R10 coefficient
High-voltage generator
Capacity
7KVA
Max DC output voltage
90KV
Max DC output current
100mA
X-Ray tube
Model
0XD4-2.9/100
Focus
Small focus 1.8×1.8mm big focus4.3×4.3mm
Radiographic table
Length×width×height of bed surface
2000mm×665mm×700mm
Moving range of bed surface
640mm in Length,200mm in breadth
Ray-filter of table
Travel in length ≥50mm
Grid density N=28
Convergence distance f。=100cm
Grid ratio r=8
Column of X-ray tube unit
Moving Longitudinally along
Radiographic table
1000mm or 1800mm
Distance to friend as moving up and down (along column)
650~1800mm
Rotary around the center of cross arm
±180°
Rotary around the shaft line of X-ray annular tubes
-10°~60°~ +120°
Max size of cassette

356mm×432mm(14″×17″)
Our Company

Factory

Quality Workplace

Good Labor relations

testing equipment

Team


Speak fluent English

Well-trained and professional sales

More than 10 years of experience engineers

Our customers

We have sold our products to more than 50 countries ,like The Democratic Republic of Congo, Saudi Arabia, Nigeria, Zambia, Angola, Egypt, Kenya, Ghana, Paraguay, Nepal and Myanmar and so on.

Our professional sales staff to help you make better purchasing decisions

Packing & Delivery
Delivery
DHL/EMS/FedEx/TNT/Ups etc.



Delivery Details
1.We ship goods by UPS/DHL/FEDEX/ TNT express takes 3~ 5 days to arrive , which is door to door  ,you   no need go out  can  get LTX21A portable diagnosis digital X-ray machine.
2.We  can   also   help  you  ship   by   air cargo, it  takes about  2-7 days  to arrive, while   you   need   to  go  to  Air   port   to take LTX21A portable diagnosis digital X-ray machine.
3.If  goods  are  large  quantity  and  you need not so urgently ,you can choose by sea   to  save  some   freight  cost   which takes    you   about   one   month   to    get LTX21A portable diagnosis digital X-ray machine.

No matter what delivery way ,depending on your actual requirements...

Our Service

Pre-Sales Service

* For all your inquires about us, we will reply you in detail within 24 hours.
* We own well-trained and professional sales who can speak fluent English.
*We offer OEM services. We can print your own logo on LTX21A portable diagnosis digital X-ray machine, also can customize the retail box packing and other things.

*Machine warranty: 1year
* View our company.

After-Sales Service

* We have very experienced engineers,can help you better use LTX21A portable diagnosis digital X-ray machine. Training how to instal the machine, training how to use the machine.
*If has product fault need to repair, please contact us, and we will cooperate with your engineers to try to deal the fault in the local firstly, so as to minimize the transportation and other cost.
*We will guide you how to deal the troubleshooting, and your engineers follow our guidance to solve fault.
*If need parts for replacement, we will send to you.
*If still can not solve the fault at last, please arrange to deliver the fault parts back to us for repair.

FAQ

Q:What's the minimum order quantity (MOQ)?

A:For most of our medical products, even order for only one unit is warmly welcomed.

Q: Can you do OEM/ private label?

A: Of course we can do OEM/private label for you.

Q: What's your delivery time?

A: Generally it is 10 days if the goods are in stock.

or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: How to ship the order?

A: Please inform us your instruction, by sea, by air or by express, any way is ok for us. We have very professional forwarder to provide the best shipping cost, service and guarantee.

Q: What is your terms of payment ?

A: We accept T/T ,LC,Western Union ,Escrow ,Paypal and more.Please suggest your preferred payment method.
