Model No. Parameters
LTSI24 Single Channel Syringe Pump
Rate Mode, Rate-Time, Rate-VTBI, Time-VTBI, Body Weight
Double CPU to make sure higher standard infusion
20 drug list with drug code display
00: 01~99: 59 （Hour: Min）
Flow Rate Step by
0.1 ml/h when Rate <100ml/h, 1ml/h when Rate ≥100ml/h
Flow Rate Range
5ml Syringe 0.1ml/h-150ml/h
10ml Syringe 0.1ml/h-300ml/h
20ml Syringe 0.1ml/h-600ml/h
30ml Syringe 0.1ml/h-900ml/h
50/60ml Syringe 0.1ml/h-1200ml/h
Purge/Bolus Rate/Top Flow Rate
5ml Syringe 150ml/h
10ml Syringe 300ml/h
20ml Syringe 600ml/h
30ml Syringe 900ml/h
50/60ml Syringe 1200ml/h
Audible & Visible Alarms
Auto Seft-Test, Syringe Dislocation, Occlusion, Near End, Syringe Empty, VTBI Completion, Low Battery, Battery Exausted, Motor Malfunction, Incorrect Syringe Specification, Circuit Malfunction, Master CPU Malfunction, Monitoring CPU Malfunction, Parameters Over Limitation, A.C Disconnection, A.C connection
Max Infusion Pressure
Lithium battery, 11.1/2000mAh
Class II, type CF, IPX4
Ambulance DC 12V
