LT1006F Automatic 6 Channel rechargeable Electrocardiograph EKG/ECG machine

Model NO.
USD 350.00-540.00 / set
Minimum order quantity:
1 set
Supply Ability:
1000 set / Month
Country of Origin:
  • Type:Examination Therapy Equipments
  • Place of Origin:CN;GUA
  • Instrument classification:Class II
  • Warranty:1 Year
  • After-sale Service:Online technical support
  • Brand Name:LEYTE
  • Model Number:LT1006F
  • Monitor:5.7 Inches
  • Channel:6
  • storage:over 400 ECG reports
  • CMRR:≥ 100dB, with AC Filter
  • Dimension:450mm*185mm*350mm
  • Weigh:4.5kg
  • Input circuit:Floating
  • Input circuit current:≤ 0.1uA
  • Resolution:12bit/1000Hz
  • Certificate:CE
Product Description

LT1006F Automatic 6 Channel rechargeable Electrocardiograph EKG/ECG machine

Function Features

Modern in design, light in weight, compact in size.

Simultaneously acquisition of 12 lead, full screen display of 12 channel ECG waveforms.

5.7'' color touch-screen, both push-button and touch operation. 4.3"color touch screen can be choose.

Sensitive filters of ADS, HUM, and EMG.

Automatic measurement, calculation, analysis, waveform freezing. Auto-analyze and auto-diagnostic can reduce doctor's burden and improve working efficiency.

Automatic adjustment of baseline for optimal recording.

Thermal printer with 112mm print paper, synchronization print

Lead off & lack off paper detection function.

Built-in rechargeable li-ion battery (11.1V/4000mAh), AC/DC power conversion.

Adapt to 100-240V, 50/60Hz AC power supply

Historical data and patient's information can be reviewed and printed.

Support USB flash disk & SD memory, stored reports can be saved, opened, analyzed in PC via ECG playback software.

The machine can store over 400 ECG reports in its built-in flash.

Standard RS232 and USB communication interfaces.

Connect with PC via ECG workstation software.

Sleep mode to save energy and extend LCD life

The device can record real time clear and exact 12 channel ECG waveform and remark continually. The remark includes: lead sign, sensitivity, paper speed, filter state, etc.

≥ 100dB, with AC Filter
Input circuit
Input circuit current
≤ 0.1µ A
Operation mode
AC. EMG Filter
Drift filter
Anti-Drift System
Input Impedance
Patient current leakage
< 10µ A
Specification of fuse
T1.6A 250V Ø5×20
Recording paper
Thermal recording paper
Calibrating voltage
1mV± 3%
Voltage tolerance
± 500mV
Time constant
Frequent response
Noise level
≤ 15µ Vp-p
≤ 20µ V
Paper speed
12.5, 25, 50mm/s (± 3%)
5, 10, 20mm/mV
High resolution thermal printer
Built-in rechargeable Li-ion battery 11.1V(4000mAh)

Unit Package

Paking size: 450mm*185mm*350mm

Gross Weight: 4.5Kg
